Manuals

One manual per product: what it is, how it is wired, how it is commissioned, and the reference for each firmware or application it runs.

• CAN-CANCAN gateway for third-party equipment: NMEA 2000, J1939, Scheiber, watermakers, bus extender.
• CAN-SERIALCAN gateway for serial equipment — VE.Direct or Modbus, four channels.
• CAN-MDVRemote battery switch, battery readings from a LIN sensor, and power injection.
• CAN-ENOCEANWireless, battery-free wall switches published on the MUXEN network.
• BLOC 8 v2Power distribution: eight measured, protected, dimmable outputs with a local front panel.
• BRAIN 2.0The onboard computer: MUXEN services, NMEA 2000 bridge, the boat's network, and the software stack inside it.

Common to every box — identifiers, addressing, firmware update and the system LED, described once for the whole range.

Drawings — the enclosures on one A4 sheet each: outside dimensions, mounting holes and the fixing specification.
